Cisco Firepower 1010 Hardware Installation Guide

Figure 31: Tighten the Velcro Straps
—Velcro straps tightened over power supply1
Step 8 Slide the sliding rack tray into the rack shelf.
Figure 32: Slide the Sliding Rack Tray Into the Rack Shelf
Step 9 The chassis is now installed in the sliding rack tray, which is installed in the rack shelf. Repeat Steps 1 through 8 to
install a second chassis. Use the second sliding rack tray and remaining three M3 x 7-mm screws to install a second
chassis to the sliding rack tray and then onto the rack shelf (see Step 3).
Cisco Firepower 1010 Hardware Installation Guide
35
Mount the Chassis
Rack-Mount the Chassis

Cisco Firepower 1010 Specifications

General

VPN Throughput	500 Mbps
Concurrent Sessions	100, 000
Maximum Concurrent Sessions	200, 000
Ports	8 x 1 GE
Humidity	10% to 90% non-condensing
Form Factor	Desktop
Flash Memory	8 GB
Interfaces	8 x RJ-45
Power Supply	Internal
Dimensions (H x W x D)	4.44 x 21.59 x 17.27 cm
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-20 to 70°C
Memory	4 GB
