Figure 34: Console Port Connection
USB Mini B to USB Type A console cable2USB Mini B console port1
USB Type A3
Step 4 Connect the end of the cable with the DB-9 connector (or USB Type A) to the terminal or PC. If your terminal or PC has
a console port that does not accommodate a DB-9 connector, you must provide an appropriate adapter for that port.
The LED for the console port turns green and within a few moments the Found New Hardware Wizard appears.
Step 5 Follow the instructions to complete the driver installation.
Step 6 To communicate with the chassis, start a terminal emulator application. This software should be configured with the
following parameters:
9600 baud
8 data bits
Cisco Firepower 1010 Hardware Installation Guide
38
Connect to the Console Port
Connect to the Console Port with Microsoft Windows

Other manuals for Cisco Firepower 1010

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cisco Firepower 1010 and is the answer not in the manual?

Cisco Firepower 1010 Specifications

General IconGeneral
VPN Throughput500 Mbps
Concurrent Sessions100, 000
Maximum Concurrent Sessions200, 000
Ports8 x 1 GE
Humidity10% to 90% non-condensing
Form FactorDesktop
Flash Memory8 GB
Interfaces8 x RJ-45
Power SupplyInternal
Dimensions (H x W x D)4.44 x 21.59 x 17.27 cm
Operating Temperature32°F to 104°F (0°C to 40°C)
Storage Temperature-20 to 70°C
Memory4 GB
