Cisco IR829 Integrated Services Router Hardware Installation Guide
Chapter 1 Product Overview
Antennas
Transportation Use Case 2:
7 x RF ports, with the IR829 deployed
in a transportation application.
(Alternate Configuration, can be used in
case the application calls for the WiFi
antennas to be separate from the LTE
antenna for example. a ceiling mount
WLAN).
This case describes a Tercia 3-in-1
transportation antenna (which covers
MIMO cellular and GPS) together with
qty 2 x 2-in-1 WiFi antennas.
Note A CUSTOM CEILING
MOUNT BRACKET IS
REQUIRED FOR THE 2-in-1
antenna if installed in a ceiling
mount configuration (NOT
SUPPLIED BY CISCO)
No extension cables are required if the
IR829 unit is located within ~1.0ft of
3-in-1 antenna, and ~2.0ft of WiFi 2-in-1
antenna.
If these conditions are not met, this
deployment requires the following
extension cables:
Cellular extension cables:
(2 ports)
Qty 2X LMR-400-DB TNC(m)-R/A -
TNC(f), 5ft
• 4G-CAB-LMR400-5
• 37-100842-01
— OR
Qty 2X LMR-400-DB TNC(m)-R/A -
TNC(f), 10ft
• 4G-CAB-LMR400-10
• 37-100843-01
— OR
Qty 2X LMR-400-LLPL plenum / indoor
only
TNC(m)-R/A - TNC(f), 20ft
• 4G-CAB-ULL-20
• 37-1401-01
— AND
WiFi 2.4 GHz / 5GHz extension cables (4
ports, can mix and match lengths per
installation requirements if needed)
Qty 4x LMR-400-DB RPTNC(plug) -
STR RPTNC(jack) - STR, 5ft
• AIR-CAB005LL-R
• 37-0766-01
— OR
Qty 4x LMR-400-DB RPTNC(plug)-R/A
RPTNC(jack)-STR, 10ft
• CAB-L400-10-R
• 37-100844-01
— AND
GPS port - No extension cable required,
3-in-1 antenna comes with integrated
active GPS antenna with 17ft cable.
Tercia 3 element 3-in-1 transportation
antenna, black radome color, 2x 4G
cellular, 1xGPS
• ANT-3-4G2G1-O
• 07-100263-01
Has the following integrated cables:
qty 2 x cellular, LMR-195, 2ft long,
TNC(m)
qty 1 x GPS, RG-174, 17ft long,
SMA(m)
— AND
QTY 2 of 2-in-1 antennas
WiFi 2-in-1 2 element 2 in 1
transportation antenna, black radome
color, 2x dual band WiFi
• ANT-2-WLAN-D-O
• 07-100265-01
Has the following integrated cables:
qty 2 x WiFi, 3ft long, LMR-240
RPTNC (plug)
Note A CUSTOM CEILING
MOUNT BRACKET IS
REQUIRED FOR THE 2-in-1
antenna if installed in a ceiling
mount configuration (NOT
SUPPLIED BY CISCO)
Use Case Extension Cable Antenna
