1-10
Cisco IR829 Integrated Services Router Hardware Installation Guide
Chapter 1 Product Overview
Antennas
MIMO ports on 5-in-1 and 2-in-1
Cellular and WLAN ports on the 5-in-1 and 2-in-1 antennas support MIMO technology. MIMO brings
significant improvements in throughput and robustness of the wireless link in fading channels. Users
choosing to connect only one wireless port on MIMO capable products are giving up significant wireless
performance in both throughput and robustness of the link.
• The individual 4G antenna cables on the 5-in-1 antenna can be connected to either cellular port of
IR829. There is no one-to-one assignment requirement.
• The individual WLAN antenna cables on the 5-in-1 antenna and the 2-in-1 antenna can be connected
to any WLAN port of IR829. There is no one to one assignment requirement.
The following section shows some examples of different installation scenarios.
Supported Cisco Antennas and Cables
Table 1-4 lists the supported 4G/LTE Radio Modules/Cables/Antennas for Cisco IR829.
Ta b l e 1-4 4G/LTE Radio Modules/Cables/Antennas
Use Case Radio Module Indoor Cable
Lightning
Arrestor or
Adapter
Outdoor Cable Antenna
4G/LTE Case 1:
1' 2', 5', 10', 15' or 20'
cable to mast mounted
antenna, Stick Omni
or Directional Flat
Panel antenna
IR829GW-LTE
-GA-EK9
IR829GW-LTE
-GA-ZK9
IR829GW-LTE
-NA-AK9
IR829GW-LTE
-VZ-AK9
2x TNC(f)
None
Router located in
outdoor protective
enclosure
None RA-TNC(m) to
N(m),
LMR-400-DB,
20', qty 2
• 37-1378-01
• "CAB-L400-2
0-TNC-N
2x 4G Omni Stick,
Standard Perf, 10”
2dBi, 1x N(f) each
• 07-1171-01
• ANT-4G-OMNI-O
UT-N
1x 4G Panel Antenna,
2x N(f) each
• 07-1172-01
• ANT-4G-PNL-OUT
-N
4G/LTE Case 2: IR829GW-LTE
-GA-EK9
IR829GW-LTE
-GA-ZK9
IR829GW-LTE
-NA-AK9
IR829GW-LTE
-VZ-AK9
2x TNC(f)
R/A-TNC(m) to
N(m),
LMR-240-FR/CMR,
2’, qty 2
• 37-100707-01
Note Not
available
from Cisco
1x 4G Panel Antenna,
2x N(f) each
• 07-1172-01
• ANT-4G-PNL-OUT
-N
