Cisco MERAKI MS425 Series User Manual

1. Install the mounting cage nuts in the rack being used for the switch.
2. Separate the rack mount rails, and install the rack mount rails channel onto the rack.
Note: This installation guide details how to mount the switch into a rack using rack mount rails, which however are not part of the package. Nor do we
sell them as accessory.
6

Cisco MERAKI MS425 Series Specifications

General

Stacking Ports	2 x 40G QSFP+
Layer Support	Layer 3
VLAN Support	Yes, up to 4094 VLANs
ACL Support	Yes
QoS Support	Yes
PoE Support	No
Operating Temperature	32°F to 104°F (0°C to 40°C)
Operating Humidity	5% to 95% non-condensing
Model	MS425-16, MS425-32
Forwarding Rate	476 Mpps
Ports	16 x 10G SFP+
Management	Managed via the Meraki cloud
Stacking	Yes
