Network Interfaces
NCS-57B1
The Cisco NCS-57B1 Router has the following hardware features:
• 24 ports of 100G QSFP-DD.
• 6 ports of 400G QSFP-DD. Applicable for NCS-57B1-6D24-SYS.
• 5 ports of 400G QSFP-DD. Applicable for NCS-57B1-5DSE-SYS.
Figure 7: NCS-57B1-5DSE-SYS—Front View
12 QSFP-DD ZR ports1
12x100G QSFP-DD ports
Only even ports support QSFP-DD 100G-ZR
Note
2
5x400G QSFP-DD ports3
Figure 8: NCS-57B1-6D24-SYS—Front View
12 QSFP-DD ZR ports1
12x100G QSFP-DD ports
Only even ports support QSFP-DD 100G-ZR
Note
2
Hardware Installation Guide for Cisco NCS 5700 Series Fixed-Port Routers
11
NCS 5700 Router Overview
Network Interfaces
