Cisco NCS 5700 Series

Figure 36: Extend the Middle Slider Member
Middle slider member1
Step 6 Insert the inner slider members (attached to the chassis or tray) to the middle slider member on the rack.
Step 7 Slide the chassis or tray into middle slider member until it cannot be pushed further.
Hardware Installation Guide for Cisco NCS 5700 Series Fixed-Port Routers
49
Install the Chassis
Rack Mount the NCS-57C3-MOD Chassis in a 4-Post Rack using Sliders
