Figure 48: NCS 57B1 Console, TOD, and Management Port Location

Console port2Time of Day (ToD) port1

Management Ethernet port4USB3

Hardware Installation Guide for Cisco NCS 5700 Series Fixed-Port Routers

Connect Router to the Network

Connect to the Console Port
