Cisco Nexus 1000V - VSM Creation

22-9
Cisco Nexus 1000V Troubleshooting Guide, Release 5.2(1)SV3(1.1)
OL-31593-01
Chapter 22 System
VSM Creation
VSM Creation
Port Profiles
When creating a port profile, use the following commands to create the corresponding port groups on
the vCenter Server:
• vmware port-group
• state enabled
Profiles that have the system VLAN configuration allow the VEM to communicate with the VSM.
Make sure that the system port-profile is defined with the right system VLANS.
Use the show port-profile and show port-profile usage commands to collect basic required
information.
Example:
switch(config)# module vem 3 execute vemcmd show port 48
LTL IfIndex Vlan Bndl SG_ID Pinned_SGID Type Admin State CBL Mode Name
17 1a030100 1 T 304 1 32 PHYS UP UP 1 Trunk vmnic1
switch(config)#
Step 3
module vem module_number execute vemcmd set
mtu size ltl port-LTL-number
Example:
switch(config)# module vem 3 execute vemcmd
set mtu 9000 ltl 17
switch(config)#
Designates the MTU size for the port, using the LTL number
obtained in Step 2.
Command Description
Symptom Possible Causes Solution
The VSM VM is stuck at the
boot prompt.
— Make sure that you have three e1000
NICs.
The VSM VM cannot ping
itself.
— Configure the management0 interface.
The VSM VM can ping
itself, but not the gateway.
— Make sure the NIC order is correct:
control, management, inband/outband.
The VSM VM can ping the
gateway, but not the outside
subnet.
— Configure vrf context management.
