Number-8 Phillips flat-head screws (4 each bracket)3Rear-mounting position1
Front-mounting position2
c) Secure the bracket to the chassis using four Number-8 Phillips flat-head screws and tighten each screw to 12 in-lb
(1.36 N·m) of torque.
d) Repeat previous step for the other front rack-mount bracket on the other side of the switch and be sure to position
that bracket the same distance from the front of the switch.
Cisco Nexus 9348GC-FXP ACI Mode Hardware Installation Guide
20
Installing the Switch Chassis
Installing the Switch into a Two-post Rack
