A-1
Cisco Redundant Power System Hardware Installation Guide
OL-3654-01
APPENDIX
A
Technical Specifications
The technical specifications for the Cisco RPS are listed in Table A-1.
Table A-1 Specifications
Environmental Ranges
Operating temperature 32 to 104°F (0 to 40°C)
Storage temperature –4 to 149°F (–20 to 65°C)
Operating humidity 10 to 85% (noncondensing)
Storage humidity 5 to 95% (noncondensing)
Operating altitude Up to 10,000 ft (3,000 m)
Storage altitude Up to 15,000 ft (4,570 m)
Normal operating noise level 48 dBa
Power Requirements
Nominal input voltage
Current
Frequency
Absolute maximum input
100 to 240 VAC autoranging
10A maximum
50 to 60 Hz
1000W
Output voltage/maximum current +5VDC at 24A,
+12VDC at 5A,
–12VDC at 3 A
Output power 150W per module (maximum)
