Page #111 background imageLoading...
Page #111 background image
Configuring Virtual Private Networks (VPNs) and Security
Configuring VPNs
Cisco RV 120W Administration Guide 103
5
To quickly set up a VPN tunnel using VPN Wizard:
STEP 1 Choose IPsec > VPN Wizard.
STEP 2 Set the Connection Name and Pre-Shared key. The connection name is used for
management, and the pre-shared key will be required on the VPN client or
gateway to establish the tunnel.
STEP 3 Choose the Remote Gateway Type (IP Address or Fully-Qualified Domain Name).
STEP 4 Enter the Remote WAN IP Address/Internet Name.
STEP 5 Choose the Local Gateway Type (IP Address or Fully-Qualified Domain Name).
STEP 6 Enter the Local WAN IP Address/Internet Name. This field can be left blank if you
are not using a different FQDN or IP address than the one specified in the WAN
port configuration.
STEP 7 Configure the LAN accessibility details in the Secure Connection Remote
Accessibility section:
Remote LAN IP address
Remote LAN Subnet Mask
NOTE The IP address range used on the remote LAN must be different from the IP
address range used on the local LAN.
STEP 8 Click Save.
STEP 9 The Wizard creates a corresponding IKE policy with the following default values
(these can be accessed from a link on the Wizard page):
