Cisco RV 120W Administration Guide

Configuring Virtual Private Networks (VPNs) and Security
Configuring VPNs
Cisco RV 120W Administration Guide 109
5
STEP 3 Enter the information in the following sections and press Save.
General Parameters
STEP 1 Enter a unique name to identify the policy.
STEP 2 Choose the Policy Type:
• Manual—All settings (including the keys) for the VPN tunnel are manually
input for each end point. No third-party server or organization is involved.
• Auto—Some parameters for the VPN tunnel are generated automatically.
This requires using the IKE (Internet Key Exchange) protocol to perform
negotiations between the two VPN Endpoints.
To create an Auto VPN Policy, you need to first create an IKE policy and then add
the corresponding Auto Policy for that IKE Policy.
STEP 3 In the Remote Endpoint field, select the type of identifier that you want to provide
for the gateway at the remote endpoint: IP Address or FQDN (Fully Qualified
Domain Name).
STEP 4 In the Enable NetBIOS field, check this box to allow NetBIOS broadcasts to travel
over the VPN tunnel, or uncheck this box to disable NetBIOS broadcasts over the
VPN tunnel. For client policies, the NetBIOS feature is available by default.
Local Traffic Selection and Remote Traffic Section
STEP 1 For both of these sections, configure the following settings:
• Local/Remote IP—Select the type of identifier that you want to provide for
the endpoint:
- Any—Specifies that the policy is for traffic from the given end point
(local or remote). Note that selecting Any for both local and remote end
points is not valid.
- Single—Limits the policy to one host. Enter the IP address of the host
that will be part of the VPN in Start IP Address field.
- Range—Allows computers within an IP address range to connect to the
VPN. Enter the Start IP Address and End IP Address in the provided
fields.
