Cisco RV180 Administration Guide

Configuring the Firewall
Configuring Port Forwarding
Cisco RV180/RV180W Administration Guide 91
4
• TACACS (Terminal Access Controller Access-Control System)
• TELNET (command)
• TFTP (Trivial File Transfer Protocol)
• RIP (Routing Information Protocol)
• IKE
• SHTTPD (Simple HTTPD web server)
• IPSEC-UDP-ENCAP (UDP Encapsulation of IPsec packets)
• IDENT protocol
• VDOLIVE (live web video delivery)
• SSH (secure shell)
• SIP-TCP or SIP-UDP
STEP 5 Select the Source IP:
• Any—Specifies that the rule being created is for traffic from the given
endpoint.
• Single Address—Limit to one host. Requires the IP address of the host to
which this rule would be applied.
• Address Range—This is used to apply this rule to a group of computers/
devices within an IP address range. Requires a from IP address and to IP
address.
STEP 6 If you chose Single Address in Step 5, enter the IP address in the Start field.
STEP 7 If you chose Address Range in Step 5, enter the starting IP address of the range in
the Start field and the ending IP address of the range in the Finish field.
STEP 8 If you chose Always Allow, Block by Schedule, or Allow by Schedule in Step 3:
a. Enter the Destination IP address, or the address where traffic meeting the rule
should be sent.
b. In the Internal Port field, enter the port to which traffic should be forwarded.
STEP 9 Click Save.

Cisco RV180 Specifications

General

WAN Ports	1
LAN Ports	4
VPN Support	Yes
Wireless Support	No
Firewall	Yes
Device Type	VPN Router
VPN Tunnels	10
Authentication	MD5, SHA1
Power Supply	12V DC, 1A
Encryption	3DES, AES
VPN Protocols	IPSec
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 70 °C
Humidity	10% to 85% non-condensing
Dimensions	130 x 130 x 35 mm
Weight	0.28 kg
