Cisco RV180 Administration Guide

Configuring Networking
Configuring the WAN (Internet) Settings
Cisco RV180/RV180W Administration Guide 25
2
Configuring Automatic Configuration (DHCP)
If your Internet Service Provider (ISP) uses the Dynamic Host Configuration
Protocol (DHCP) to assign you an IP address, you receive a dynamic IP address
from your ISP.
To configure DHCP WAN settings:
STEP 1 Choose Networking > WAN (Internet) > IPv4 WAN (Internet).
STEP 2 From the Internet Connection Type drop-down menu, choose
Automatic Configuration - DHCP.
STEP 3 Enter MTU information. (See Configuring MTU Settings, page 28.)
STEP 4 Enter MAC Address information. (See Configuring the MAC Address, page 29.)
STEP 5 Click Save.
Configuring Static IP
If your ISP assigned you a permanent IP address, perform the following steps to
configure your WAN settings:
STEP 1 Choose Networking > WAN (Internet) > IPv4 WAN (Internet).
STEP 2 From the Internet Connection Type drop-down menu, choose Static IP.
STEP 3 Enter this information:
IP Address Enter the IP address that your ISP has assigned to
you.
Subnet mask Enter subnet mask that your ISP has assigned to
you.
Default Gateway Enter the IP address of the IPS’s gateway.
Primary DNS Server Enter the IP address of the primary DNS server
used by your ISP.
Secondary DNS Server (Optional) Enter the IP address of the secondary
DNS server. This is used if the primary DNS server
fails.

Cisco RV180 Specifications

General

WAN Ports	1
LAN Ports	4
VPN Support	Yes
Wireless Support	No
Firewall	Yes
Device Type	VPN Router
VPN Tunnels	10
Authentication	MD5, SHA1
Power Supply	12V DC, 1A
Encryption	3DES, AES
VPN Protocols	IPSec
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 70 °C
Humidity	10% to 85% non-condensing
Dimensions	130 x 130 x 35 mm
Weight	0.28 kg
