Cisco RV180 Administration Guide

Configuring Networking
Configuring Routing
Cisco RV180/RV180W Administration Guide 41
2
STEP 5 Click Save.
Configuring Jumbo Frames
A standard Ethernet frame contains 1,500 bytes of data. Enabling the Jumbo
Frames feature allows the switch to send jumbo frames within the LAN containing
up to 9,000 bytes of data per frame. You can configure the Cisco RV180/RV180W
to support jumbo frames. After support is enabled, devices on the LAN side of the
network can exchange traffic that contains jumbo frames. To configure jumbo
frames:
STEP 1 Choose Networking > LAN > Jumbo Frames.
STEP 2 Check the Enable box.
STEP 3 Click Save.
Configuring Routing
Choosing the Routing Mode
The Cisco RV180/RV180W provides two different routing modes. Network
Address Translation (NAT), or gateway routing, is a technique that allows several
endpoints on a LAN to share an Internet connection. The computers on the LAN
use a “private” IP address range while the WAN port on the router is configured
with a single “public” IP address. The Cisco RV180/RV180W translates the internal
private addresses into a public address, hiding internal IP addresses from
computers on the Internet. If your ISP has assigned you a single IP address, you
want to use NAT so that the computers that connect through the Cisco RV180/
RV180W are assigned IP addresses from a private subnet (for example,
192.168.10.0).
Port Cost The cost of using the interface-based connection.

Cisco RV180 Specifications

General

WAN Ports	1
LAN Ports	4
VPN Support	Yes
Wireless Support	No
Firewall	Yes
Device Type	VPN Router
VPN Tunnels	10
Authentication	MD5, SHA1
Power Supply	12V DC, 1A
Encryption	3DES, AES
VPN Protocols	IPSec
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 70 °C
Humidity	10% to 85% non-condensing
Dimensions	130 x 130 x 35 mm
Weight	0.28 kg
