Cisco RV180 Administration Guide

Introduction
Getting to Know the Cisco RV180W
Cisco RV180/RV180W Administration Guide 5
1
button for at least 20 seconds. This will restore the factory defaults and
clear all of the Cisco RV180 settings.
NOTE We recommend that you back up your current configuration before
resetting the device to the factory default settings. See Backing Up and
Restoring the System, page 151.
LAN Ports (1-4)—These ports provide a LAN connection to network devices,
such as PCs, print servers, or additional switches.
WAN Por t—The WAN port is connected to your Internet device, such as a cable or
DSL modem.
ON/OFF Power Switch—Press this button to turn the Cisco RV180 on and off.
When the button is pushed in, power is on.
Power Port—The power port is where you connect the AC power cable.
Getting to Know the Cisco RV180W
Front Panel
POWER—The Power LED lights up green to indicate the device is powered on. It
flashes green when the power is coming on or software is being upgraded.

Cisco RV180 Specifications

General

WAN Ports	1
LAN Ports	4
VPN Support	Yes
Wireless Support	No
Firewall	Yes
Device Type	VPN Router
VPN Tunnels	10
Authentication	MD5, SHA1
Power Supply	12V DC, 1A
Encryption	3DES, AES
VPN Protocols	IPSec
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 70 °C
Humidity	10% to 85% non-condensing
Dimensions	130 x 130 x 35 mm
Weight	0.28 kg
