Cisco RV180 Administration Guide

Introduction
Saving Your Changes
Cisco RV180/RV180W Administration Guide 19
1
Click a menu item (numbered 2 in Figure 1) on the left panel to expand it. Click the
menu names displayed underneath to perform an action or view a sub-menu.
NOTE The RV180W menus change depending on the router mode (Router, Access Point,
WDS Bridge, or WDS Repeater) that you have configured for the RV180W. For
example, the RV180W in WDS Bridge mode displays fewer choices under the
Security menu than the RV180W in router mode.
On the RV180W, the upper right of the screen (numbered 3 in Figure 1) shows in
which device mode the RV180W is running.
Figure 1 RV180W Device Manager
Saving Your Changes
When you finish making changes on a configuration page, click Save (numbered 4
in Figure 1) to save the changes, or click Cancel (numbered 5 in Figure 1) to undo
your changes.

Cisco RV180 Specifications

General

WAN Ports	1
LAN Ports	4
VPN Support	Yes
Wireless Support	No
Firewall	Yes
Device Type	VPN Router
VPN Tunnels	10
Authentication	MD5, SHA1
Power Supply	12V DC, 1A
Encryption	3DES, AES
VPN Protocols	IPSec
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 70 °C
Humidity	10% to 85% non-condensing
Dimensions	130 x 130 x 35 mm
Weight	0.28 kg
