Chapter 4 Installing the Cisco SCE8000 Chassis
Installing the Cisco SCE8000 Chassis in the Rack
Installing the Chassis in the Rack
Caution To prevent personal injury or damage to the chassis, never attempt to lift or tilt the chassis using the
handles on modules (such as power supplies, fans, or cards); these types of handles are not designed to
support the weight of the unit. Lift the unit only by grasping the chassis underneath its lower edge.
To install the Cisco SCE8000 chassis in the equipment rack, perform these steps:
Step 1 Position the chassis in the rack as follows:
• If the front of the chassis (front panel) is at the front of the rack, insert the rear of the chassis between
the mounting posts.
• If the rear of the chassis is at the front of the rack, insert the front of the chassis between the
mounting posts.
Step 2 Align the mounting holes in the bracket (and optional cable guide) with the mounting holes in the
equipment rack.
Step 3 Use a tape measure and level to choose and mark the position that the chassis is to be installed in the
rack. Make a mark at equal height on both sides of the rack. This will help ensure that the chassis will
be installed straight and level.
