Cisco SCE8000 Installation And Configuration Guide

CHAPTER
6-1
Cisco SCE8000 Installation and Configuration Guide, Rel 3.1.7
OL-16478-03
6
Cabling the Line Ports and Completing the
Installation
This chapter provides instructions for cabling the Cisco SCE8000 10 Gigabit Ethernet ports for single,
cascaded, and MGSCP topologies. In a cascade topology, this includes the cascade ports as well as the
line ports.
The 10 Gigabit Ethernet ports are located on the 10G SPA modules, which are installed in the
SCE8000-SIP module in slot #3 of the Cisco SCE8000 chassis.
Note When installing a cascaded system, it is extremely important to follow the sequence of procedures
outlined in the section Cascaded Systems, page 6-15.
Note When installing an External Optical Bypass module, the Cisco SCE8000 line ports are connected to the
module. See Cabling the 10GBE Line Interface Ports: Using the External Optical Bypass Module,
page 6-11 for complete instructions.
• Connecting the Line Ports to the Network, page 6-1
• The Optical Bypass Module, page 6-8
• Cabling the 10GBE Line Interface Ports, page 6-9
• How to Load and Activate a Service Control Application, page 6-14
• Cascaded Systems, page 6-15
Connecting the Line Ports to the Network
• Single Link: Inline Topology, page 6-2
• Single Link: Receive-only Topology, page 6-2
• Dual Link: Single Cisco SCE8000 Topologies, page 6-2
• Dual Link: Two Cisco SCE8000s Topology, page 6-3
• Multi-Gigabit Service Control Platforms (MGSCP) Topologies, page 6-4
