Chapter 6 Cabling the Line Ports and Completing the Installation
Cabling the 10GBE Line Interface Ports
Optical Bypass Module Connectivity
• Single Link Topology, page 6-9
• Dual Link Topology, page 6-9
Single Link Topology
A single link requires only one bypass module.
• Subscriber side network element <->Port A on the bypass module
• Cisco SCE8000 port 3/0/0 <->Port C on the bypass module
• Network side network element <->Port B on the bypass module
• Cisco SCE8000 port 3/1/0 <->Port D on the bypass module
• CTRL <->left-hand 'Optical Bypass' port on Cisco SCE8000-SCM-E module.
Dual Link Topology
A dual link requires two bypass modules.
• Subscriber side network element <->Port A on bypass module #1
• Cisco SCE8000 port 3/0/0 <->Port C on bypass module #1
• Network side network element <->Port B on bypass module #1
• Cisco SCE8000 port 3/1/0 <->Port D on bypass module #1
• CTRL on bypass module #1 <->left-hand 'Optical Bypass' port on Cisco SCE8000-SCM-E module.
• Subscriber side network element <->Port A on bypass module #2
• Cisco SCE8000 port 3/2/0 <->Port C on bypass module #2
• Network side network element <->Port B on bypass module #2
• Cisco SCE8000 port 3/3/0 <->Port D on bypass module #2
• CTRL on bypass module #2 <->right-hand 'Optical Bypass' port on Cisco SCE8000-SCM-E
module.
Cabling the 10GBE Line Interface Ports
Note When installing an External Optical Bypass module, the Cisco SCE8000 line ports are connected to the
module. See Cabling the 10GBE Line Interface Ports: Using the External Optical Bypass Module,
page 6-11 for complete instructions.
Warning Class 1 laser. Avoid exposure to radiation and do not stare into open aperture.
• Fiber Specifications, page 6-10
• Optical Device Maintenance, page 6-10
• How to Cable the 10GBE Line Interface Ports, page 6-10
• Cabling the 10GBE Line Interface Ports: Using the External Optical Bypass Module, page 6-11
