6-18
Cisco SCE8000 Installation and Configuration Guide, Rel 3.1.7
OL-16478-03
Chapter 6 Cabling the Line Ports and Completing the Installation
Cascaded Systems
The following link mode options are available:
• Forwarding — forwards traffic on the specified link to the SCE platform for processing.
• Bypass — stops all forwarding of traffic on the specified link to the SCE platform. Traffic still flows
on the link, but is not processed in any way by the SCE platform.
This does not affect the redundancy states.
• Cutoff — completely cuts off flow of traffic through the specified link.
Note the following recommendations and restrictions:
• Link mode is relevant only to inline topologies.
• It is recommended that in cascaded topologies, both SCE platforms be configured for the same link
mode, otherwise the service will be unpredictable.
• The default link mode is forwarding. When other link modes are selected, active service control is
not available and any service control configuration will not be applicable.
Step 1 From the Cisco SCE8000 (config if)# prompt, type link mode [forwarding|bypass|cutoff] and press
Enter.
Monitoring the System
Use the following commands to view the current connection mode and link mode parameters.
• How to View the Current Connection Mode, page 6-18
• How to View the Current Link Mode, page 6-18
• How to View the Current Link Mappings, page 6-18
How to View the Current Connection Mode
Step 1 From the Cisco SCE8000# prompt, type show interface linecard 0 connection-mode and press Enter.
How to View the Current Link Mode
Step 1 From the Cisco SCE8000# prompt, type show interface linecard 0 link mode and press Enter.
How to View the Current Link Mappings
Step 1 From the Cisco SCE8000# prompt, type show interface linecard 0 physically-connected-links and
press Enter.
