Port Management
Configuring LACP
Cisco Small Business 300 Series Managed Switch Administration Guide 96
9
• If the port LACP priority of the link is lower than that of the currently-active
link members, and the number of active members is already at the maximum
number, the link is made inactive, and placed in standby mode.
Setting Port LACP Parameter Settings
The LACP Page displays and enables configuration of the LACP System Priority,
LACP timeout, and LACP port priority. LACP timeout is a per port parameter, and is
the time interval between the sending and receiving of consecutive LACP PDUs.
With all factors equal, when the LAG is configured with more candidate ports than
the maximum number of active ports allowed, the switch selects ports as active
from the dynamic LAG that has the highest priority
NOTE The LACP setting is irrelevant on ports that are not members of a dynamic LAG.
To d e f i n e t h e L A C P s e t t i n g s :
STEP 1 Click Port Management > Link Aggregation > LACP. The
LACP Page
opens.
STEP 2 Enter the global LACP System Priority value that determines which candidate
ports will become members of the LAG.
The page displays the LACP settings of every port. You can select and edit the
desired port by using the Edit LACP Page
STEP 3 Select a port, and click Edit. The
Edit LACP Page
opens.
STEP 4 Enter the values for the following fields:
• Port—Select the port number to which timeout and priority values are
assigned.
• LACP Port Priority—Enter the LACP priority value for the port.
• LACP Timeout—Select the periodic transmissions of LACP PDUs occur at
either a slow or fast transmission rate, depending upon the expressed LACP
timeout preference.
STEP 5 Click Apply. The switch is updated.
You can continue editing by selecting another port in the Port field.
