Configuring Quality of Service
Managing QoS Statistics
Cisco Small Business 300 Series Managed Switch Administration Guide 270
18
Policy Binding
The Policy Binding Page shows which policy profile is bound and to which port.
When a policy profile is bound to a specific port, it is active on that port. Only one
policy profile can be configured on a single port, but a single policy can be bound
to more than one port.
When a policy is bound to a port, it filters and applies QoS to ingress traffic that
belongs to the flows defined in the policy. The policy does not apply to traffic
egress to the same port.
To edit a policy, it must first be removed (unbound) from all those ports to which it
is bound.
To define policy binding:
STEP 1 Click Quality of Service > QoS Advanced Mode > Policy Binding. The Policy
Binding Page opens.
STEP 2 Select a Policy Name.
STEP 3 Select the Interface Type assigned to the policy.
STEP 4 Click Apply. The QoS policy binding is defined, and the switch is updated.
Managing QoS Statistics
Viewing Policer Statistics
A Single Policer is bound to a class map from a single policy. An Aggregate Policer
is bound to one or more class maps from one or more policies.
Viewing Single Policer Statistics
The Single Policer Statistics Page
indicates the number of in-profile and out-of-
profile packets that are received from an interface that meet the conditions
defined in the class map of a policy.
NOTE This page is not displayed when the switch is in Layer 3 mode.
