Managing Power-over-Ethernet Devices
Configuring PoE Properties
Cisco Small Business 300 Series Managed Switch Administration Guide 104
10
To configure PoE on the switch and monitor current power usage:
STEP 1 Click Port Management > PoE > Properties. The
PoE Properties Page
opens.
STEP 2 Enter the values for the following fields:
• Power Mode—Select one of the following options:
- Port Limit—The maximum power limit per each port is configured by the
user.
- Class Limit—The maximum power limit per port is determined by the
class of the device, which results from the Classification stage.
• Traps—Enable or disable traps. If traps are enabled, you must also enable
SNMP and configure at least one SNMP Notification Recipient.
• Power Trap Threshold—Enter the usage threshold that is a percentage of the
power limit. An alarm is initiated if the power exceeds this value.
The following counters are displayed:
• Nominal Power—The total amount of power the switch can supply to all the
connected PDs.
• Consumed Power—Amount of power currently being consumed by the PoE
ports.
• Available Power—Nominal power - the amount of consumed power.
