Configuring Quality of Service
Managing QoS Statistics
Cisco Small Business 300 Series Managed Switch Administration Guide 273
18
STEP 3 Enter the parameters.
• Counter Set—Select the counter set:
- Set 1—Displays the statistics for Set 1 that contains all interfaces and
queues with a high DP (Drop Precedence).
- Set 2—Displays the statistics for Set 2 that contains all interfaces and
queues with a low DP.
• Interface—Select the ports for which statistics are displayed. The options
are:
- Port—Selects the port on the selected unit number for which statistics
are displayed.
- All Ports—Specifies that statistics are displayed for all ports.
• Queue—Select the queue for which statistics are displayed.
• Drop Precedence—Enter drop precedence that indicates the probability of
being dropped.
STEP 4 Click Apply. The Queue Statistics counter is added, and the switch is updated.
