Administration: Discovery
Discover - LLDP
Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x 116
8
- Active—Is the type of traffic active on the port.
- Application—Type of traffic for which the policy is defined.
• Location—Whether Location TLV is transmitted.
• PoE—Whether PoE-PSE TLV is transmitted.
• Inventory—Whether Inventory TLV is transmitted.
STEP 2 The message at the top of the page indicates whether the generation of the LLDP MED
Network Policy for the voice application is automatic or not (see LLDP Overview). Click on
the link to change the mode.
STEP 3 To associate additional LLDP MED TLV and/or one or more user-defined LLDP MED
Network Policies to a port, select it, and click Edit.
STEP 4 Enter the parameters:
• Interface—Select the interface to configure.
• LLDP MED Status—Enable/disable LLDP MED on this port.
• SNMP Notification—Select whether SNMP notification is sent on a per-port basis
when an end station that supports MED is discovered; for example a SNMP managing
system, when there is a topology change.
• Selected Optional TLVs—Select the TLVs that can be published by the device by
moving them from the Available Optional TLVs list to the Selected Optional TLVs list.
• Selected Network Policies—Select the LLDP MED policies to be published by LLDP
by moving them from the Available Network Policies list to the Selected Network
Policies list. These created in the LLDP MED Network Policy page. To include one or
more user-defined network polices in the advertisement, you must also select Network
Policy from the Available Optional TLVs.
NOTE The following fields must be entered in hexadecimal characters in the exact data
format that is defined in the LLDP-MED standard (ANSI-TIA-
1057_final_for_publication.pdf):
- Location Coordinate—Enter the coordinate location to be published by LLDP.
- Location Civic Address—Enter the civic address to be published by LLDP.
- Location ECS ELIN—Enter the Emergency Call Service (ECS) ELIN location to
be published by LLDP.
STEP 5 Click Apply. The LLDP MED port settings are written to the Running Configuration file.
