Cisco SG350-28 User Manual

Security: IPv6 First Hop Security
IPv6 First Hop Security Overview
Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x 538
25
IPv6 First Hop Security Overview
IPv6 FHS is a suite of features designed to secure link operations in an IPv6-enabled network.
It is based on the Neighbor Discovery Protocol and DHCPv6 messages.
In this feature, a Layer 2 switch (as shown in Figure 1) filters Neighbor Discovery Protocol
messages, DHCPv6 messages and user data messages according to a number of different rules.
Figure 1 IPv6 First Hop Security Configuration
A separate and independent instance of IPv6 First Hop Security runs on each VLAN on which
the feature is enabled.
Abbreviations
IPv6 Host
(End Node)
Monitor
First Hop Switch IPv6 Router
370572
Name Description
CPA message Certification Path Advertisement message
CPS message Certification Path Solicitation message
DAD-NS message Duplicate Address Detection Neighbor Solicitation
message
FCFS-SAVI First Come First Served - Source Address Validation
Improvement

Cisco SG350-28 Specifications

General

Model	SG350-28
Category	Switch
Switching Capacity	56 Gbps
Layer	Layer 3
Power Supply	Internal
Form Factor	Rack-mountable
Relative Humidity	10% to 90% non-condensing
MAC Address Table Size	16K entries
Power Dedicated to PoE	Not applicable
Dimensions (W x D x H)	440 x 257 x 44 mm
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Power Consumption	24W
Input Voltage	100-240V AC, 50/60Hz
Jumbo Frame Support	Supported
Weight	3.2 kg
