Smartport
Common Smartport Tasks
183 Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x
10
Workflow2: To configure an interface as a static Smartport, perform the following
steps:
STEP 1 To enable the Smartport feature on the interface, open the Interface Settings page.
STEP 2 Select the interface, and click Edit.
STEP 3 Select the Smartport type that is to be assigned to the interface in the Smartport Application
field.
STEP 4 Set the macro parameters as required.
STEP 5 Click Apply.
Workflow3: To adjust Smartport macro parameter defaults and/or bind a user-defined
macro pair to a Smartport type, perform the following steps:
Through this procedure you can accomplish the following:
• View the macro source.
• Change parameter defaults.
• Restore the parameter defaults to the factory settings.
• Bind a user-defined macro pair (a macro and its corresponding anti-macro) to a
Smartport type.
1. Open the Type Settings page.
2. Select the Smartport Type.
3. Click View Macro Source to view the current Smartport macro that is associated with the
selected Smartport Type.
4. Click Edit to open a new window in which you can bind user-defined macros to the selected
Smartport type and/or modify the default values of the parameters in the macros bound to
that Smartport type. These parameter default values are used when Auto Smartport applies
the selected Smartport type (if applicable) to an interface.
5. In the Edit page, modify the fields.
6. Click Apply to return the macro if the parameters changed.
