Cisco SG350-28 User Manual

Dashboard
Port Utilization
Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x 26
2
• Display Mode—Chart View
A list of ports is displayed. The port utilization is displayed in bar format:
For each port, the following port utilization information is displayed:
Tx—% (green)
Rx—% (blue)
• Refresh Time—Select one of the displayed options.
• Interface Statistics—Lick to link to the Status and Statistics -> Interface page.

Cisco SG350-28 Specifications

General

Model	SG350-28
Category	Switch
Switching Capacity	56 Gbps
Layer	Layer 3
Power Supply	Internal
Form Factor	Rack-mountable
Relative Humidity	10% to 90% non-condensing
MAC Address Table Size	16K entries
Power Dedicated to PoE	Not applicable
Dimensions (W x D x H)	440 x 257 x 44 mm
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Power Consumption	24W
Input Voltage	100-240V AC, 50/60Hz
Jumbo Frame Support	Supported
Weight	3.2 kg
