Cisco SG350-28 User Manual

Configuration Wizards
ACL Wizard
35 Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x
3
• Time Range Name—If Time Range is selected, select the time range to be used. Time
ranges are defined in the System Time Configuration section. This field is only
displayed if a Time Range was previously created.
STEP 8 Click Next.
STEP 9 Confirm that you want the ACL and ACE to be created.
The details of the ACL rule are displayed. You can click Add another rule to this ACL to
add another rule.
STEP 10 Click Next and enter the ACL Binding information:
• Binding Type—Select one of the following options to bind the ACL:
- Physical interfaces only—Bind the ACL to a port. In this case, click a port or ports
on which to bind the ACL.
- VLANs only—Bind the ACL to a VLAN. Enter the list of VLANs in the Enter the
list of VLANs you want to bind the ACL to field.
- No binding—Do not bind the ACL.
Click Apply.

Cisco SG350-28 Specifications

General

Model	SG350-28
Category	Switch
Switching Capacity	56 Gbps
Layer	Layer 3
Power Supply	Internal
Form Factor	Rack-mountable
Relative Humidity	10% to 90% non-condensing
MAC Address Table Size	16K entries
Power Dedicated to PoE	Not applicable
Dimensions (W x D x H)	440 x 257 x 44 mm
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Power Consumption	24W
Input Voltage	100-240V AC, 50/60Hz
Jumbo Frame Support	Supported
Weight	3.2 kg
