VLAN Management
Customer Port Multicast TV VLAN
Cisco 500 Series Stackable Managed Switch Administration Guide Release 1.3 246
13
After a CPE VLAN is mapped to a Multicast VLAN, it can participate in IGMP
snooping.
To m a p C P E V L A N s :
STEP 1 Click VLAN Management > Customer Port Multicast TV VLAN > CPE VLAN to
VLAN.
STEP 2 Click Add.
STEP 3 Enter the following fields:
CPE VLAN—Enter the VLAN defined on the CPE box.
Multicast TV VLAN—Select the Multicast TV VLAN which is mapped to the
CPE VLAN.
STEP 4 Click Apply. CPE VLAN Mapping is modified, and written to the Running
Configuration file.
CPE Port Multicast VLAN Membership
The ports associated with the Multicast VLANs must be configured as customer
ports (see Configuring VLAN Interface Settings).
Use the Port Multicast VLAN Membership page to map these ports to Multicast TV
VLANs as described in Port Multicast VLAN Membership
