IP Configuration
IPv4 Management and Interfaces
Cisco 500 Series Stackable Managed Switch Administration Guide Release 1.3 288
17
If a static IP address is used, configure the following fields.
• IP Address—Enter the IP address, and configure one of the following Mask
fields:
- Network Mask—Select and enter the IP address mask.
- Prefix Length—Select and enter the length of the IPv4 address prefix.
• Administrative Default Gateway—Select User Defined and enter the
default gateway IP address, or select None to remove the selected default
gateway IP address from the interface.
• Operational Default Gateway—Displays the current default gateway
status.
NOTE If the device is not configured with a default gateway, it cannot
communicate with other devices that are not in the same IP subnet.
If a dynamic IP address is retrieved from the DHCP server, select those of the
following fields that are enabled:
• Renew IP Address Now—The device dynamic IP address can be renewed
any time after it is assigned by a DHCP server. Note that depending on your
DHCP server configuration, the device might receive a new IP address after
the renewal that requires setting the web-based configuration utility to the
new IP address.
• Auto Configuration via DHCP—Displays status of Auto Configuration
feature. You can configure this from
Administration
>
File Management
>
DHCP Auto Configuration
.
STEP 3 Click Apply. The IPv4 interface settings are written to the Running Configuration
file.
Defining IPv4 Interface in Layer 3 System Mode
The IPv4 Interface page is used when the device is in Layer 3 system mode. This
mode enables configuring multiple IP addresses for device management, and
provides routing services.
The IP address can be configured on a port, a LAG, or VLAN interface.
