Overview of Widgets
Widgets
About Widgets
The Touch10/DX In-Room Control panel is composed of user
interface elements called widgets. You can nd the complete
widget library in the right pane of the In-Room Control editor.
General tab: Buttons with custom text, group buttons, toggle
button, sliders, text elds and more.
Icons tab: Buttons with familiar symbols for Home, Power, Arrow
up/down/left/right, Camera controls, Loudspeaker controls,
Microphone control, Media player controls, and more.
Each of the widget type available are described on the
following pages, with emphasis on:
•
Commands that change the value of the widget
•
Events that are sent (pressed, changed, released, clicked) and
which actions trigger these events
•
Examples of commands and events, both in terminal output
mode and XML output mode.
Syntax and semantics for all events, commands and statuses that
are related to in-room controls (user interface extensions) are
included in the Command reference chapter.
The Widget Identier
All widgets on a Touch10/DX in-room control panel need a
unique identier, a WidgetID. The WidgetID may either be
dened by you, or assigned automatically. The WidgetID can be
any name or number; we recommend using a descriptive name
without special characters. The maximum number of characters
is 40.
The WidgetID is the programming link between Touch10/DX,
the video system, and the control system. The WidgetID will be
included in all events that are associated with a widget, and you
must use the same identier when you send commands to that
widget via the code that you write for your control system.
Group Identiers
One of the widgets, the Group button, has two types of
identiers: The WidgetID refers to the complete group of buttons,
while GroupIDs are unique identiers for the individual buttons
within the group.
Option 1 Option 2 Option 3
Widget_ID_groupbutton
Group_ID_one Group_ID_two Group_ID_three
A GroupID is assigned automatically, but can be dened by you
instead. A GroupID can be any name or number; we recommend
using a descriptive name without special characters. The
maximum number of characters is 255.

Cisco Touch10 Specifications

General

Display Size	10.1 inches
Resolution	1280 x 800 pixels
Touch Technology	Capacitive
Connectivity	Ethernet, Wi-Fi
Power	Power over Ethernet (PoE)
Mounting	Tabletop or wall mount
Processor	ARM-based processor
Compatibility	Cisco video conferencing systems
