7-20
Cisco TrustSec Configuration Guide
OL-22192-01
Chapter 7 Cisco TrustSec Command Summary
cts policy layer3
Configure Cisco TrustSec Layer 3 SGT transport with these usage guidelines and restrictions:
• The Cisco TrustSec Layer 3 SGT transport feature can be configured only on ports that support
hardware encryption.
• Traffic and exception policies for Cisco TrustSec Layer 3 SGT transport have the following
restrictions:
–
The policies must be configured as IP extended or IP named extended ACLs.
–
The policies must not contain deny entries.
–
If the same ACE is present in both the traffic and exception policies, the exception policy takes
precedence. No Cisco TrustSec Layer 3 encapsulation will be performed on packets matching
that ACE.
• Traffic and exception policies can be downloaded from the authentication server (if supported by
your Cisco IOS Release) or manually configured on the device with the ip access-list global
configuration command. The policies will be applied based on these rules:
–
If a traffic policy or an exception policy is downloaded from the authentication server, it will
take precedence over any manually configured traffic or exception policy.
–
If the authentication server is not available but both a traffic policy and an exception policy have
been manually configured, the manually configured policies will be used.
–
If the authentication server is not available but a traffic policy has been configured with no
exception policy, no exception policy is applied. Cisco TrustSec Layer 3 encapsulation will be
applied on the interface based on the traffic policy.
–
If the authentication server is not available and no traffic policy has been manually configured,
no Cisco TrustSec Layer 3 encapsulation will be performed on the interface.
Examples The following example shows how to configure Layer 3 SGT Transport to a remote Cisco TrustSec
domain:
Router# configure terminal
Router(config)# ip access-list extended traffic-list
Router(config-ext-nacl)# permit ip any 10.1.1.0 0.0.0.255
Router(config-ext-nacl)# exit
Router(config)# ip access-list extended exception-list
Router(config-ext-nacl)# permit ip any 10.2.2.0 0.0.0.255
Router(config-ext-nacl)# exit
Router(config)# cts policy layer3 ipv4 traffic traffic-sgt
Router(config)# cts policy layer3 ipv4 exception exception-list
Router(config)# interface gi2/1
Router(config-if)# cts layer3 trustsec ipv4 forwarding
Router(config-if)# shutdown
Router(config-if)# no shutdown
Router(config-if)# exit
Router(config)# exit
Related Commands Command Description
cts layer3 Enables and applies traffic and exception policies to CTS
Layer 3 Transport gateway interfaces.
show cts policy layer3 Displays the traffic and exception policies used in CTS
Layer3 Transport.
