7-27
Cisco TrustSec Configuration Guide
OL-22192-01
Chapter 7 Cisco TrustSec Command Summary
cts role-based policy trace
Command Default There are no defaults.
Command Modes Privileged EXEC
Supported User Roles Administrator
Command History
Usage Guidelines The cts role-based policy trace procedure is summarized as follows:
1. Discover the network path.
Know the topology of the entire TrustSec network before executing the command. Standard network
discovery methods such as IP traceroute, CDP or other methods can be used to obtain this
information.
2. Starting from the host and continuing to the farthest node; log-in to each device in the path.
3. Execute the cts role-based policy trace command on each device.
Based on the input arguments, the command output reports the outgoing SGT value and SGACL
entry/ACE. Apply the SGT value from the output as the input SGT on the next switch in the path.
If you do not provide the (optional) SGT argument in the command line, the output reports the SGT
assigned to the packet along with any available binding information.
For example, a packet may be dropped because a device is blocking UDP packets, which may indicate a
problem with an SGACL configuration or SGACL refresh obtained from another device, such as the
Cisco Integrated Services Engine (Cisco ISE). The policy trace command would identify on which
device the SGACL was enforced and which ACE was blocking.
Examples The following example specifies a source interface on the source host for an xdmcp over UDP packet.
switch# cts role-based policy trace ipv4 udp host 10.2.2.1 eq 177 host 10.1.1.2 eq 80 int
giga 1/1
Input Qualifiers:
====================
Input Interface : Gi 1/1
Packet Parameters:
=====================
security-group
{sgname sg_name | sgt
sgt_num}
Optional. Specifies the Security Group name or the Security Group Tag
number.
vlan vlan_id Optional. 0 to 4094. Specifies the VLAN identifier.
vrf vrf_name Optional. Specifies the Virtual Routing and Forwarding instance name.
Release Modification
15.1(1)SY1 This feature was introduced on the Catalyst 6500 series switches.
