Chapter 7 Cisco TrustSec Command Summary
sap (cts manual interface submode)
sap (cts manual interface submode)
Use the sap mode-list command to manually specify the Pairwise Master Key (PMK) and the Security
Association Protocol (SAP) authentication and encryption modes to negotiate MACsec link encryption
between two interfaces. Use the no form of the command to revert to the default.
[no] sap pmk hex_value [modelist {gcm-encrypt | gmac | no-encap | null} [gcm-encrypt | gmac
| no-encap | null] . . . ]
Syntax Description
Defaults The default encryption is sap modelist gcm-encrypt null. When the peer interface does not support
dot1x, 802.1AE MACsec, or 802.REV layer-2 link encryption, the default encryption is null.
Command Modes CTS manual interface configuration submode (config-if-cts-manual)
Supported User Roles Administrator
Command History
Usage Guidelines The Security Association Protocol (SAP) is an encryption key derivation and exchange protocol based
on a draft version of the 802.11i IEEE protocol. In a TrustSec configuration, the keys are used for
MACsec link-to-link encryption between two interfaces.
If 802.1X authentication is not possible, SAP, and the Pairwise Master Key (PMK) can be manually
configured between two interfaces with the sap pmk command. When using 802.1X authentication, both
sides (supplicant and authenticator) receive the PMK and the MAC address of the peer’s port from the
Cisco Secure Access Control Server.
Examples The following example shows a SAP configuration for a Gigabit Ethernet interface:
router(config)# interface gigabitEthernet 2/1
router(config-if)# cts manual
router(config-if-cts-manual)# sap pmk FFFEE mode-list gcm-encrypt
pmk hex_value Hex-data PMK (without leading 0x; enter even number of hex chars else last
char prefixed with 0)
modelist List of advertised modes (prioritized from highest to lowest)
gcm-encrypt Specifies GCM authentication, GCM encryption
gmac Specifies GCM authentication, no encryption
no-encap Specifies no encapsulation
null Specifies encapsulation present, no authentication, no encryption
Release Modification
12.2(50) SY This command was introduced on the Catalyst 6500 Series Switches.
