Figure 20: TPM Socket Location
TPM socket on
motherboard
2Front of server1
Step 2 Enable TPM Support in the BIOS.
If TPM support was disabled for any reason, use the following procedure to enable it.
a) In the Cisco UCS Manager Navigation pane, click the Servers tab.
b) On the Servers tab, expand Servers > Policies.
c) Expand the node for the organization where you want to configure the TPM.
d) Expand BIOS Policies and select the BIOS policy for which you want to configure the TPM.
e) In the Work pane, click the Advanced tab.
f) Click the Trusted Platform sub-tab.
g) To enable TPM support, click Enable or Platform Default.
h) Click Save Changes.
i) Continue with the next step.
Step 3 Enable TXT Support in the BIOS Policy.
Follow the procedures in the Cisco UCS Manager Configuration Guide for the release that is running on the
server.
Servicing a Blade Server
24
Servicing a Blade Server
Enabling the Trusted Platform Module
