Cisco UCS C200 M2 High-Density SFF Drive Rack-Mount Server
SUPPLEMENTAL MATERIAL
47
Recommended Configurations
Table 24 lists the recommended DIMM combinations for 1- and 2-socket CPU systems. The DIMM
combinations yielding the best performance are noted.
Table 24 Recommended DIMM Combinations
Total Memory Size CPU Socket 1 CPU Socket 2
DIMM Max
Clock rate
Tota l
DIMMs in
System
DIMM
Bank 1
DIMM
Bank 2
DIMM
Bank 1
DIMM
Bank 2
8 GB (1 CPU)
16 GB (2 CPUs)
1 x 8 GB — 1 x 8 GB — 1333 MHz 2
2 x 4 GB — 2 x 4 GB — 1333 MHz 4
12 GB (1 CPU)
24 GB (2 CPUs)
3 x 4 GB — 3 x 4 GB — 1333 MHz
6
1
Notes . . .
1. Best performance configuration
16 GB (1 CPU)
32 GB (2 CPUs)
1 x 16 GB — 1 x 16 GB — 1066 MHz 2
2 x 8 GB — 2 x 8 GB — 1333 MHz 4
2 x 4 GB 2 x 4 GB 2 x 4 GB 2 x 4 GB 1333 MHz 8
24 GB (1 CPU)
48 GB (2 CPUs)
3 x 8 GB — 3 x 8 GB — 1333 MHz
6
1
3 x 4 GB 3 x 4 GB 3 x 4 GB 3 x 4 GB 1333 MHz
12
1
32 GB (1 CPU)
64 GB (2 CPUs)
2 x 16 GB — 2 x 16 GB — 1066 MHz 4
2 x 8 GB 2 x 8 GB 2 x 8 GB 2 x 8 GB 1333 MHz 8
36 GB (1 CPU)
72 GB (2 CPUs)
3 x 8 GB 3 x 4 GB 3 x 8 GB 3 x 4 GB 1333 MHz
12
1
48 GB (1 CPU)
96 GB (2 CPUs)
3 x 16 GB — 3 x 16 GB — 1066 MHz 6
3 x 8 GB 3 x 8 GB 3 x 8 GB 3 x 8 GB 1333 MHz
12
1
60 GB (1 CPU)
120 GB (2 CPUs)
3 x 16 GB 3 x 4 GB 3 x 16 GB 3 x 4 GB 800 MHz 12
64 GB (1 CPU)
128 GB (2 CPUs)
2 x 16 GB 2 x 16 GB 2 x 16 GB 2 x 16 GB 800 MHz 8
72 GB (1 CPU)
144 GB (2 CPUs)
3 x 16 GB 3 x 8 GB 3 x 16 GB 3 x 8 GB 800 MHz 12
96 GB (1 CPU)
192 GB (2 CPUs)
3 x 16 GB 3 x 16 GB 3 x 16 GB 3 x 16 GB 800 MHz 12

Cisco UCS C200 M2 Specifications

General

Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF8
Processor cache	4 MB
Processor cores	4
Processor model	E5506
System bus rate	4.8 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Motherboard chipset	-
Processor frequency	2.13 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	16
Maximum number of SMP processors	2
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800 MHz
Memory bandwidth supported by processor (max)	19.2 GB/s
Maximum internal memory supported by processor	144 GB
HDD size	- \
RAID levels	0, 1
Optical drive type	DVD-RW
Total storage capacity	0 GB
Maximum storage capacity	0 TB
Number of HDDs installed	0
Internal memory	4 GB
Maximum internal memory	96 GB
Memory layout (slots x size)	1 x 4 GB
Graphics card	G200
Networking features	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power supply	650 W
Power requirements	AC 120/230 V, 50/60 Hz
Chassis type	Rack (1U)
Processor ARK ID	37096

Weight and Dimensions

Depth	706.1 mm
Width	429.3 mm
Height	43 mm
