Cisco UCS C200 M2 User Manual

Cisco UCS C200 M2 High-Density SFF Drive Rack-Mount Server
50
SUPPLEMENTAL MATERIAL
RACKS
The Cisco R42610 rack (see Figure 11) is certified for Cisco UCS installation at customer sites and is
suitable for the following equipment:
■ Cisco UCS B-Series servers and fabric interconnects
■ Cisco UCS C-Series and select Nexus switches
The rack is compatible with hardware designed for EIA-standard 19-inch racks. Rack specifications are
listed in
Table 25.s
Table 25 Cisco R42610 Rack Specifications
Parameter Standard Rack Expansion Rack
Dimensions (H x W x D) 78.74 x 24 x 43.38 in.
(2000 x 610 x 1102 mm)
78.74 x 23.58 x 43.38 in.
(2000 x 599 x 1102 mm)
Dimensions (H x W x D)
with packaging
89 x 33 x 47 in.
(2261 x 838 x 1194 mm)
89 x 33 x 47 in.
(2261 x 838 x 1194 mm)
Distance from front
mounting rail to rear
mounting rail
29.2 in (741 mm) 29.2 in (741 mm)
Weight 299.83 lb (136 kg) 231. 49 lb (105 kg)
Weight with packaging 354 lb
(161 kg)
284 lb
(129 kg)
Side panels included Yes No
Equipment mounting
capacity
42RU 42RU
Static load capacity 2100 lb
(954 kg)
2100 lb
(954 kg)
Dynamic load capacity Not applicable Not applicable
NOTE: The AC input connector is an IEC 320 C-14 15 A/250 VAC power inlet.

Cisco UCS C200 M2 Specifications

General

Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF8
Processor cache	4 MB
Processor cores	4
Processor model	E5506
System bus rate	4.8 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Motherboard chipset	-
Processor frequency	2.13 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	16
Maximum number of SMP processors	2
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800 MHz
Memory bandwidth supported by processor (max)	19.2 GB/s
Maximum internal memory supported by processor	144 GB
HDD size	- \
RAID levels	0, 1
Optical drive type	DVD-RW
Total storage capacity	0 GB
Maximum storage capacity	0 TB
Number of HDDs installed	0
Internal memory	4 GB
Maximum internal memory	96 GB
Memory layout (slots x size)	1 x 4 GB
Graphics card	G200
Networking features	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power supply	650 W
Power requirements	AC 120/230 V, 50/60 Hz
Chassis type	Rack (1U)
Processor ARK ID	37096

Weight and Dimensions

Depth	706.1 mm
Width	429.3 mm
Height	43 mm
