BASE SERVER STANDARD CAPABILITIES and FEATURES
BASE SERVER STANDARD CAPABILITIES and FEATURES
Table 1 lists the capabilities and features of the base server. Details about how to configure the server for
a particular feature or capability (for example, number of processors, disk drives, or amount of memory)
are provided in
CONFIGURING the SERVER, page 8.
Table 1 Capabilities and Features
Capability/Feature Description
Chassis Single rack unit (1RU) chassis
CPU Up to two Intel® Xeon® 5600 series processors
Chipset Intel® 5520 (Tylersburg) chipset
Memory 12 slots for registered ECC DIMMS (up to 192 GB), supporting Intel SDDC
NIC Embedded dual-port Intel 82576NS PCIe-based Gigabit Ethernet controller
Expansion slots Two PCIe slots (on a riser card)
■ One full-height profile, half-length slot with x16 connector and x8 lane
■ One half-height profile, half-length slot with x8 connector and x8 lane
Storage controller One of the following:
■ An onboard SATA RAID 0/1 controller integrated on motherboard
(Intel ICH10R) that can control up to four SATA drives, or
■ An optional RAID mezzanine card:
• LSI® 1068E 8-port controller mezzanine card
(RAID levels 0 or 1) for up to eight internal SAS or SATA drives, or
■ One of these optional RAID PCIe plug-in cards:
• LSI 6G MegaRAID SAS 9260-8i controller
(RAID levels 0, 1, 5, 6, 10, 50, or 60 supported) for up to eight SAS or
SATA drives, or
• LSI 6G MegaRAID SAS 9280-4i4e Controller
(RAID levels 0, 1, 5, 6, 10, 50, or 60 supported) for up to eight SAS or
SATA drives
Internal storage devices ■ Up to eight 2.5-inch SAS or SATA hot-swappable HDDs or solid state
drives (SSDs)
■ USB connector on motherboard
Video ■ 1280 x 1024 resolution
■ 32-bit color depth
■ 8 MB video memory

Cisco UCS C200 M2 Specifications

General

Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF8
Processor cache	4 MB
Processor cores	4
Processor model	E5506
System bus rate	4.8 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Motherboard chipset	-
Processor frequency	2.13 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	16
Maximum number of SMP processors	2
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800 MHz
Memory bandwidth supported by processor (max)	19.2 GB/s
Maximum internal memory supported by processor	144 GB
HDD size	- \
RAID levels	0, 1
Optical drive type	DVD-RW
Total storage capacity	0 GB
Maximum storage capacity	0 TB
Number of HDDs installed	0
Internal memory	4 GB
Maximum internal memory	96 GB
Memory layout (slots x size)	1 x 4 GB
Graphics card	G200
Networking features	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power supply	650 W
Power requirements	AC 120/230 V, 50/60 Hz
Chassis type	Rack (1U)
Processor ARK ID	37096

Weight and Dimensions

Depth	706.1 mm
Width	429.3 mm
Height	43 mm
