Step 14 Repeat the above steps on the second fabric in your configuration.
Step 15 After both fabrics are cabled, use UCS Manager to Re-acknowledge the server.
Step 16 After both fabrics are cabled, use UCS Manager to Re-commission the servers that you decommissioned
in the first step.
After a server is discovered, it re-associates with any prior service profiles that were assigned to it.
Supported Network Adapter Cards for UCSM Mode
Network Adapter cards can be Cisco Virtual Interface Cards (VICs), Converged Network Adapters
(CNAs), or Ethernet adapters.
Supported Adapter Cards
Table D-1 shows the adapter cards that are officially supported for use in C-Series servers in UCSM
mode. Not all adapters in the table are supported in all servers, so find your server model and then read
down its column to see which adapters have been qualified for use in UCSM mode.
Supported Card Combinations
When the server is used in UCSM mode, only certain combinations of adapters have been qualified for
official support:
• Only Cisco Virtual Interface Cards (VICs) installed in the server. No mixing with CNAs or Ethernet
cards.
• Only one type of CNA (Q or E) installed in the server. No mixing with VICs or Ethernet adapters.
• Only one type of Ethernet adapter (B or I) installed in the server. No mixing with VICs or CNAs.
Ta b l e D-1 Supported Network Adapter Cards by Server
Adapter/Server Model C200 M2 C210 M2 C220 M3 C240 M3 C250 M2 C260 M2 C460 M2
Cisco UCS P81E VIC
(N2XX-ACPCI01)
Y Y Y Y Y Y Y
Emulex OCe10102-F CNA
(N2XX-AEPCI01)
Y Y Y Y Y
QLogic QLE8152 CNA
(N2XX-AQPCI01)
Y Y Y Y Y
Broadcom BCM57711 10Gb 
(N2XX-ABPCI02)
Y Y Y Y Y
Intel X520 10Gb
(N2XX-AIPCI01)
Y Y Y Y Y Y Y
