Rear Panel LEDs
Figure 3-2 shows the names and locations of the rear panel LEDs.
Figure 3-2 Rear Panel LEDs
Table 3-2 describes the possible states and interpretations for the LEDs that are shown in Figure 3-2.
1 Power supply fault LED 2 Rear Locator LED
3 10/100 Ethernet speed LED 4 10/100 Ethernet link status LED
5 10/100/1000 Gigabit Ethernet speed LED 6 10/100/1000 Gigabit Ethernet link status LED
