C-1
Cisco UCS C210 Server Installation and Service Guide
OL-20887-02
APPENDIX
C
RAID Controller Considerations
This appendix contains the following sections:
• Supported RAID Controllers and Required Cables, page C-1
• Enabling the Integrated Intel ICH10R RAID Controller in the BIOS, page C-2
• Enabling the Mezzanine Card RAID Controller in the BIOS, page C-3
• RAID Controller Cabling, page C-3
• How to Determine Which Controller Is in Your Server, page C-4
• How to Disable Quiet Boot for CIMC Firmware Earlier Than Release 1.2(1), page C-5
• How To Launch Option ROM-Based Controller Utilities, page C-5
• LSI MegaRAID Card Beep Codes, page C-6
• Restoring RAID Configuration After Replacing a RAID Controller, page C-6
• For More Information, page C-7
Supported RAID Controllers and Required Cables
This server supports the RAID controller options and cable requirements shown in Table C-1.
Note This server contains a default drive backplane called an extender, which supports controller connection
for up to 8 drives. To control more than 8 drives (maximum 16), the server must be ordered with the
optional expander backplane. The extender/expander backplanes are not field-upgradeable.
Note Different cables might be required when connecting to the extender versus the expander, as described in
Table C-1.
Note Do not mix controller types in the server. Dual controllers are not supported.
