3-6
Cisco UCS C210 Server Installation and Service Guide
OL-20887-02
Chapter
Note The 10/100/1000 Gigabit Ethernet link status LED and the speed LED must be
read in combination for the following interpretations.
10/100/1000 Gigabit
Ethernet speed (left)
10/100/1000 Gigabit
Ethernet link status (right)
• Link status off + speed off—No link is present on this port.
• Link status off + speed solid green—A half-duplex, 10-Mbps link
is present.
• Link status green + speed solid green—A half-duplex, 100-Mbps
link is present.
• Link status amber + speed solid green—A half-duplex, 1000-Mbps
link is present.
• Link status off + speed blinking green—A full-duplex, 
10-Mbps link is present.
• Link status green + speed blinking green—A full-duplex,
100-Mbps link is present.
• Link status amber + speed blinking green—A full-duplex,
1000-Mbps link is present.
Table 3-2 Rear Panel LEDs (Continued)
LED Name State
