Cisco UCS C240 M3 Specifications

Cisco UCS C240 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
44
CONFIGURING the SERVER
STEP 9 ORDER POWER SUPPLY
The C240 M3 server requires at least one power supply. A lightly loaded server may require one
or two 650 W power supplies. A fully loaded server might need to be powered with two 1200 W
power supplies. A server with one GPU requires at least one 1200 W power supply; a server with
two GPUs requires two 1200 W power supplies. Use the power calculator at the following link to
determine the needed power based on the options chosen (CPUs, drives, memory, and so on):
https://express.salire.com/Go/Cisco/Cisco-UCS-Power-Calculator.aspx
Table 18 Power Supply
Product ID (PID) PID Description
UCSC-PSU-650W 650 W power supply (CSCI platinum).
UCSC-PSU2-1200 1200 W power supply (CSCI platinum).
UCSC-PSU-930WDC 930 W -48V DC power supply
NOTE: In a two power supply server, both power supplies must be identical.

Cisco UCS C240 M3 Specifications

General

Processor cores	8
Processor model	E5-2600
Processor frequency	2.7 GHz
Number of processors installed	2
HDD size	2.5 \
RAID support	Yes
HDD interface	-
Optical drive type	No
Total storage capacity	300 GB
Maximum storage capacity	- TB
Number of HDDs installed	16
Memory slots	24
Internal memory	96 GB
Memory clock speed	1866 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
PCI Express x8 slots	3
Chassis type	Rack (2U)
Power supply	650 W
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Operating temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	712 mm
Width	445 mm
Height	87 mm
