Cisco UCS C240 M3 - DIMM Population Order

Cisco UCS C240 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
SUPPLEMENTAL MATERIAL
67
DIMM Population Order
Populate the DIMMs for a CPU according to Table 36.
Table 36 DIMM Population Order per CPU
DIMMs
per CPU
Populate
CPU 1 Slots
Populate
CPU 2 Slots
1 A1 E1
2 A1, B1 E1, F1
3 A1, B1, C1 E1, F1, G1
4 A1, B1, C1, D1 E1, F1, G1, H1
6
1
Notes . . .
1. Not recommended (for performance reasons)
A1, B1, C1,
A2, B2, C2
E1, F1, G1,
E2, F2, G2
8 A1, B1, C1, D1,
A2, B2, C2, D2
E1, F1, G1, H1,
E2, F2, G2, H2
12
A1, B1, C1, D1,
A2, B2, C2, D2
A3, B3, C3, D3
E1, F1, G1, H1,
E2, F2, G2, H2
E3, F3, G3, H3
