CONFIGURING the SERVER
STEP 4 SELECT RAID CONFIGURATION
The RAID controller choices are:
(1) Embedded RAID (on motherboard) (not supported in 24 HDD backplane systems)
(2) Mezzanine RAID controller cards (not supported in 1-CPU systems)
(3) PCIe RAID controller cards
Cisco can provide factory-configured RAID systems depending on the RAID controller chosen and
the number of drives ordered. Factory-configured RAID options are listed with each RAID card
description.
NOTE: For the UCSC-C240-M3S2 (16-drive server), if you do not select a mezzanine
card, a PCIe RAID controller, or one of the embedded RAID upgrade options, you will
have an embedded SATA-only RAID controller that supports up to four SATA-only
drives (RAID 0, 1, 10)
NOTE: The UCSC-C240-M3S (24-drive server) does not support embedded RAID,
which is normally installed on the motherboard and does not consume a PCIe slot.
The only RAID support available for the 24-drive version is through a PCIe RAID
controller or a mezzanine card.
NOTE: When creating a RAID volume, follow these guidelines:
■ Use the same capacity for each drive in the volume
■ Use either all SAS drives or all SATA drives
■ Use either all HDDs or all SSDs
NOTE: The number of RAID groups (virtual drives) supported per controller is as
follows:
■ Embedded RAID = 8
■ LSI MegaRAID 9271-8i or 9271CV-8i RAID controller card = 64
■ LSI MegaRAID 9285CV-8e or 9286CV-8e RAID controller card = 64
■ Cisco Nytro MegaRAID 200 GB PCIe RAID controller = 64
■ Cisco UCSC RAID SAS 2008M-8i Mezzanine Card = 16
NOTE: The RAID configuration options listed in Table 8 on page 24 are not available
if you choose embedded RAID (in this case, you must configure RAID yourself using
separate software).
