Cisco UCS C240 M3 Specifications

Cisco UCS C240 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
50
CONFIGURING the SERVER
STEP 13 ORDER CISCO FLEXIBLE FLASH SD CARD MODULE (OPTIONAL)
You can order up to two optional preloaded 16 GB Cisco Flexible Flash secure digital (SD) cards.
The first SD card contains preloaded software for simplified server operation. The ordering
information is listed in
Table 22.
See Figure 7 on page 63 for the location of the SD cards. There are two locations, SD1 and SD2.
Table 22 Secure Digital (SD) Card (preloaded with software)
Product ID (PID) PID Description
UCSC-SD-16G-C240 16GB SD Card for C240 servers
NOTE: You can order an optional second blank SD card. The PID for the second SD
(blank) card is shown in
Table 23. The second SD card can be used to mirror the first
SD card.
Table 23 Second Secure Digital (SD) Card (blank)
Product ID (PID) PID Description
UCS-SD-16G 16GB SD Card (optional)

Cisco UCS C240 M3 Specifications

General

Processor cores	8
Processor model	E5-2600
Processor frequency	2.7 GHz
Number of processors installed	2
HDD size	2.5 \
RAID support	Yes
HDD interface	-
Optical drive type	No
Total storage capacity	300 GB
Maximum storage capacity	- TB
Number of HDDs installed	16
Memory slots	24
Internal memory	96 GB
Memory clock speed	1866 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
PCI Express x8 slots	3
Chassis type	Rack (2U)
Power supply	650 W
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Operating temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	712 mm
Width	445 mm
Height	87 mm
