Cisco UCS C240 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
CONFIGURING the SERVER
23
Select RAID Options
Select as follows (these choices are dependent on the number of CPUs installed and the
backplane used (24-drive or 16-drive backplane)):
■ One embedded RAID upgrade option for internal drives, or
■ One mezzanine RAID controller for internal drives, or
■ One mezzanine RAID controller for internal drives and one RAID controller for external
drives, or
■ One RAID controller for internal drives, or
■ One RAID controller for internal drives and one RAID controller for external drives, or
■ Two RAID controllers for internal drives
NOTE: For details on all valid combinations of embedded RAID, mezzanine RAID, and
internal/external drive RAID controller combinations, see
RAID Details, page 72.
Table 6 Available Embedded RAID Options
Product ID (PID) PID Description
Embedded RAID Controllers (16-drive backplane server option only)
UCSC-RAID-ROM5 Onboard RAID, consisting of a plug-in storage controller unit (SCU), supporting
up to 8 internal SAS +SATA drives. SAS and SATA drives can be mixed. This
option supports RAID 0, 1, and 10, and operates at 3 Gb/s. Operating systems
supported are Windows and Linux only (no VMware support).
UCSC-RAID-ROM55 Onboard RAID, consisting of two plug-in modules (an SCU plus a software key
module) supporting up to 8 internal SAS+SATA drives. SAS and SATA drives can
be mixed. This option supports RAID 0, 1, 5, and 10 and operates at 3 Gb/s.
Operating systems supported are Windows and Linux only (no VMware
support).
Table 7 Available Mezzanine Card RAID Options
Product ID (PID) PID Description
Mezzanine RAID Controllers (not supported in 1-CPU systems)
NOTE: VMware ESX/ESXi or any other virtualized environments are not supported
for use with the embedded MegaRAID controller. Hypervisors such as Hyper-V, Xen, or
KVM are also not supported for use with the embedded MegaRAID controller
